LTE BG95 Cat M1/ Cat NB2/ EGPRS Module BG95 is a series of multi-mode LPWA modules supporting LTE Cat M1/Cat NB2/EGPRS and integrated GNSS. It is 3GPP Rel. 14 compliant and offers maximum data rates of 588Kbps downlink and 1119Kbps uplink under LTE Cat M1. It features ultra-low power consumption by leveraging the integrated RAM/flash as well as the ARM Cortex A7 processor supporting ThreadX, achieving up to 70% reduction in PSM leakage and 85% reduction in eDRX current consumption compared to its predecessor. BG95 boasts a comprehensive set of hardware-based security features and enables trusted applications to run directly on the Cortex A7 TrustZone engine. Additionally, BG95 provides pin-to-pin compatibility with Quectel LTE Cat 4 modules EG91/EG95, LTE Cat M1/Cat NB1/EGPRS module BG96, NB-IoT module BC95, UMTS/HSPA modules UG95/UG96 and GSM/GPRS module M95. With a cost-effective SMT form factor of 23.6mm × 19.9mm × 2.2mm and high integration level, BG95 enables integrators and developers to easily design their applications and take advantage from the modules low power consumption and mechanical intensity. Its advanced LGA package allows fully automated manufacturing for high-volume applications. A rich set of Internet protocols, industry-standard interfaces and abundant functions extend the applicability of the module to a wide range of M2M applications such as wireless POS, smart metering, tracking, wearable devices, etc. Key Benefits LTE Cat M1/Cat NB2/EGPRS module with ultra-low power consumption Easy migration from Quectel GSM/GPRS, UMTS/HSPA and LTE modules Super slim profile in LGA package Integrated RAM and flash in the baseband chipset Comprehensive set of hardware-based security features Fast time-to-market: reference designs, evaluation tools and timely technical support minimize design-in time and development efforts Compact SMT form factor ideal for size-constrained applications with tight space Robust mounting and interfaces Specification Frequency BG95-M1 BG95-M2 BG95-M3 BG95-N1 Region/Operator For the Global For the Global For the Global For the Global LTE FDD Cat M1 Only:B1/B2/B3/B4/B5/B8/12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85 Cat M1:B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85Cat NB2:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85 Cat M1:B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85Cat NB2:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85 Cat NB2 Only:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85 GSM/EDGE / / 850/900/1800/1900MHz / GNSS (Optional) GPS/GLONASS/BeiDou/Galileo/QZSS GPS/GLONASS/BeiDou/Galileo/QZSS GPS/GLONASS/BeiDou/Galileo/QZSS GPS/GLONASS/BeiDou/Galileo/QZSS Wi-Fi (For Positioning) / / / / Certification Carrier: North America:Verizon*/AT&T*/Sprint* Regulatory: Global: GCF*Europe: CE*North America:FCC*/PTCRB*Canada: IC*Australia: RCM* Others: RoHS Carrier: North America:Verizon*/AT&T*/T-Mobile*/Sprint*South Korea:SKT*Japan:NTT DOCOMO*/SoftBank*/KDDI*Australia:Telstra* Regulatory: Global: GCF*Europe: CE*North America:FCC*/PTCRB*Canada: IC*South Korea: KC*Taiwan: NCC*Japan: JATE*/TELEC*Australia: RCM*Thailand: NBTC* Others: RoHS Carrier: Global: Vodafone*Europe:Deutsche Telekom*North America:AT&T/ Verizon*/T-Mobile*/Sprint*China:China Telecom*/ChinaMobile*/China Unicom*South Korea: SKT*Japan: NTT DOCOMO*/SoftBank*/KDDI*Australia: Telstra* Regulatory: Global: GCFEurope: CENorth America:FCC/PTCRBCanada: ICBrazil: Anatel*China: SRRC*/NAL*/CCC*South Korea: KC*Taiwan: NCC*Japan: JATE*/TELEC*Australia: RCMThailand: NBTC*Singapore: IMDA* Others: RoHS/PEN/ATEX* Carrier: North America:Verizon*/AT&T*/T-Mobile*/Sprint* Regulatory: Global: GCF*Europe: CE*North America:FCC*/PTCRB*Canada: IC*Australia: RCM* Others: RoHS Frequency BG95-M4* BG95-M5* BG95-MF (Planning) Region/Operator For the Global For the Global For the Global LTE FDD Cat M1:B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B31/B66/B72/B73/B85Cat NB2:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B31/B66/B72/B73/B85 Cat M1:B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85Cat NB2:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85 Cat M1:B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B85Cat NB2:B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66/B71/B85 GSM/EDGE / 850/900/1800/1900MHz / GNSS (Optional) GPS/GLONASS/BeiDou/Galileo/QZSS GPS/GLONASS/BeiDou/Galileo/QZSS GPS/GLONASS/BeiDou/Galileo/QZSS Wi-Fi (For Positioning) / / 2.4GHz Certification Carrier: Planning Regulatory: Planning Others: Planning Carrier: Planning Regulatory: Planning Others: Planning Carrier: Planning Regulatory: Planning Others: Planning
