Air InterfaceLTE-M, NB-IoT Region Global Operator Certifications:Global Fibocom MA510-GL-00 is a high-performance IoT module, which is tailor-made for the global IoT market. It is developed based on the Qualcomm platform and is packaged in LCC+LGA. It also supports LTE Cat-M1/ Cat-NB2/ EGPRS. Product Specifications Basic Features Cat-NB2:B1/2/3/4/5/8/12/13/18/19/20/25/26/28/66/71/85 EGPRS:850/900/1800/1900MHz GNSS:GPS/GLONASS/BeiDou/Galileo/QZSS Dimension:22.2x20.2x2.1mm Operating Temperature:-40~+85 Operating Voltage:3.3V~4.5V AT Command Set:3GPP TS 27.007 and 27.005, and proprietaryFIBOCOM AT commands TX Power:(Power Class 5) GSM850/900:32.5dBm±1dB DCS1800/PCS1900:29.5dBm±1dB Cat-M1:21dBm±1dB Cat-NB2:21dBm±1dB Data Transmission Cat-M:Max1119Kbps (DL)/ Max 375Kbps (UL) Cat-NB1:Max63.4Kbps (DL)/ Max 95.1Kbps (UL) Cat-NB2:Max127Kbps (DL)/ Max 158.5Kbps (UL) EGPRS:Max296Kbps (DL)/ Max 236.8Kbps (UL) GPRS:Max107Kbps (DL)/ Max 85.6Kbps (UL) Features Function: PPP/TCP/UDP/SSL/TLS/FTP(S)/HTTP(S) MQTT/CoAP/LWM2M VoLTE/NITZ/PING/Jamming Detection DFOTA:DFOTA Interfaces SIM:1.8V UARTx3 USB2.0x1 I2Cx1 SPIx1 I2Sx1 ADCx2 GPIOx4 OS Drivers OS Drivers:Linux, Android, Windows Certifications RoHS/HF/GCF/RCM/Telstra*/NCC/Reach FCC/IC/PTCRB/Sprint/AT&T/Verizon/ANATEL JATE/TELEC/Softbank*/DoCoMo*/KDDI CE/DT/VDF/Telefonica*
