Electrical Characteristics Antenna model: GNSS Antenna Ceramics Size(mm): 20*20/35*36 Nominal frequency: GPS L1:1575.42±1.023MHz L5: 1176.45±1.023MHz BD B1:1561.42±2.046MHz GALILEO E1:1575MHz GLONASS L1:1602±0.5625*K(MHz) V.S.W.R: 2.0 -10dB Bandwidth MHz min: 10min Gain: L1:5±1dBi L5:3±1dBi Impedance: 50 Polarization: RHCP LNA LNA Gain: L1:32±3dBi L5:28±3dBi V.S.W.R: 2.0 Noise Figure: 1.0dB Voltage: DC 3~5V Current: 15~25mA Impedance: 50 Line Length: 5cm Linear interface: IPEX Material Part Name: SPEC Antenna: Ceramics PCB: FR4 Environment Condition Working Temp: -40~+85, 10%~95%RH Storage Temp: -40~+85, 10%~95%RH Vibration: Sine sweep @1.5mmAM 10~55Hz each Axis
